Cutter attachment weight……..….1.8kg
Blade length
Long Model………..........…560mm/22in
Short Model……….........…460mm/22in
Cutter drive…….................…Spur gear
Gear lubricant……Lithium based grease
Tool kit contents………….. Combination
Wrench with 13mm+19mm
Sockets/flat blade screwdriver 4mm-hex
Wrench,and 8mm+10mm spanner
Use unit without upper tube
If the lower tube assembly is long enough,you can use it only without upper tube
according to the working condition.
Operate as follows:
1.Follow “disassemblying the pole sections” section to remove the upper tube/coupler
assembly from gearcase.
2.Follow”assembling the pole sections” section to assemble the gearcase onto the
lower tube assembly.See figure 15.
Specifications
