Coby TFTV3225S2 - Video Input Connectors; CON 2: Connector of Y;Pb;Pr-RL; Y2;Pb2;Pr2-RL; CON 5: Connector of DVD Y;Pb;Pr-RL(for TVDVD3295 model)

Service Manual
Sep. 30th, 2010 (Version 1.3) Page 12 / 21
i. CON 2: Connector of Y/Pb/Pr-RL / Y2/Pb2/Pr2-RL
j. CON 5: Connector of DVD Y/Pb/Pr-RL(for TVDVD3295 model)
PIN Symbol Description
1 GND Ground
2 R DVD R
3 L DVD L
4 GND Ground
5 Pr DVD Y/Pb/Pr
6 Pb DVD Y/Pb/Pr
7 Y DVD Y/Pb/Pr
8 GND Ground
