when the PO2 reached the current set point of 1.6 ATA. NDC times shown are
approximate.
Refer to the Analyst
®
description about how to modify parameters. During the PreDive
Prediction Mode, the unit will compute and display the maximum safe time at that depth.
Current Surface Temperature and Battery Voltage are also displayed. Battery Voltage
is displayed in the lower right hand corner of the display. Altitude is indicated in six
ranges via the Ascent Rate Bar Graph as follows (Altitude compensation is seamless
from 600m to 4.5km above sea level.
The six ranges are for display purposes only):
0 Bars sea level to 600 metres 1 Bar 600 to 1,200 metres
2 Bars 1,200 to 1,800 metres 3 Bars 1,800 to 2,400 metres
4 Bars 2,400 to 3,000 metres 5 Bars greater than 3,000 metres
METRIC
NDC
TEMP
REMAIN TIME
DEPTH
. .
Ba tteryVoltage 3.2v
21
SURFACE MODE: Surface Mode is entered after the COMMANDER+ successfully
completes its Self-Diagnostic Mode after being turned on or after the PostDive Interval
after a dive. In this mode, current Surface Time, the previous dive’s Maximum Depth,
