5.8 GHz Dual-Input Audio/Video Sender System - AVS58
www.cocoonsystems.com.au
TO TV
3. co n t r o l s a n d co n n e c t I o n s - re c e I v e r un I t
5.8 GHz
Antenna
RF Antenna
(for use with the IR
Extender feature)
ON-OFF
Switch
5.8 GHz Channel
Switch
Power Supply
Jack
RF Connection
(TV Out)
A/V Out Source 1 or 2
Selector Button
