3. co n t r o l s a n d co n n e c t I o n s - tr a n s m I t t e r un I t
5.8 GHz
Antenna
RF Antenna
(for use with the IR
Extender feature)
A/V Out Source
Selector Switch
A/V In
(Source 1)
A/V Out
IR Extender
Jack
Power Supply
Jack
A/V In
(Source 2)
5.8 GHz Channel
Switch
ON-OFF
Switch
