RIGHTRIGHTRIGHTRIGHTRIGHT LEFTLEFTLEFTLEFTLEFTLEFT RIGHT
UNBALANCED DISCTUNERVIDEOINRECORDEROUT
LEFT RIGHT
BALANCED OUTPUT
!
FOR CONTIMUED PROTECTION AGAINST
SHOCK OR FIRE HAZARD,DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
AC LINE INPUT
SEE SERIAL TAG FOR
POWER REQUIREMENTS
~
LEFT RIGHT
BALANCED DISC
UNBALANCED OUTPUT
UNBALANCED DISC
The first section of the installation instructions for the FET PREAMPLIFIER 02b is a diagram
of the basic configuration required to bring the preamplifier into an operating mode.
These brief steps will allow you to begin operating your system. Make sure during
installation that the level control is turned fully counter clockwise, all other components
are off, and AC power connections are interrupted to the preamplifier. While the
diagram may be self explanatory, we strongly recommend that you read the detailed
instructions following this introductory section.
TUNER
VIDEO
3
INSTALLATION CONNECTIONS
POWER AMP
POWER AMP
INPUT
OUTPUT
RECORDER
BALANCED DISC
