Coda 40.0 - Initial Setup; Detailed Installation

Stereo Amplier Conguration
WARNING: Please ensure that the power switch is turned OFF while you are connecting the
amplier. Connecting or disconnecting cables while the amplier is powered on could
cause damage to your speakers.
NOTE: Ensure that the mode switch located between the input jacks on the rear of the
amplier is set to the stereo position for normal operation. Bridged operation is explained on
page 7.
The diagram below shows the default connections necessary to operate the 40.0 as a
stereo amplier. This is the simplest and most common mode of operation, and the quickest
way to get started. Once these connections are made you can turn the power switch on,
enable the bias from the front panel and start listening to your amplier.
For simplicity this diagram shows an audio conguration using balanced interconnects. This
is the default input mode of the amplier. Unbalanced operation requires that you set the
appropriate input mode as detailed on page 5.
