Ku-Band BUC systems
12-50176-EN Issue 2, December 2010 Page 13 of 18
Kits
Mounting kits
Table 3: Kit, Boom Mounting, Universal to 100 W (15-42072-000)
Description Component part number
Channel, Mounting (qty 2) 05-06876
Rod, Threaded M8 × 250 mm (qty 4) 05-06904
Bracket, Mounting (qty 2) 05-07272
Spacer (qty 8) 05-07273
Rod, Threaded M8 × 180 mm (qty 4) 05-07826
Fitting Instruction, Boom Mounting, Universal to 100 W 15-42072-001
Nut, M8, Stainless steel, Hex (qty 36) 32-00800-080
Washer, M8, Stainless steel, Flat (qty 36) 32-00801-080
Washer, M8, Stainless steel, Spring (qty 36) 32-00801-280
Bolt, M8 × 50, Stainless steel, Hex (qty 4) 32-00850-080
Table 4: Kit, Mounting, 8” to 12“ Pole, RBUC, C/Ku (15-42098-000)
Description Component part number
Rod, Threaded, M8 × 250 mm (qty 4) 05-06904
Rod, Threaded, M8 × 400 mm (qty 4) 05-06984
Bracket, Mounting (qty 2) 05-07533
Fitting Instruction, Mounting, 8” to 12” Pole, RBUC,
C/Ku
15-42098-001
Nut, M8, Stainless steel, Hex (qty 25) 32-00800-080
Washer, M8, Stainless steel, Flat (qty 25) 32-00801-080
Washer, M8, Stainless steel, Spring (qty 25) 32-00801-280
Bolt, M8 × 50, Stainless steel, Hex (qty 6) 32-00850-080
