Ku-Band BUC systems
12-50176-EN Issue 2, December 2010 Page 7 of 18
AC-powered BUCs
AC-powered BUCs operate with an AC input voltage in the range 115 to 240 V AC.
Check BUC specifications for the exact voltage range of your BUC.
If you need to make your own AC mains cable, or re-terminate the cable supplied,
Table 2 lists the pin connections and describes the input functions available on the
AC INPUT connector on the BUC.
WARNING Voltages outside of these limits may cause damage to the BUC.
Table 2: Pinouts of the AC INPUT connector (Amphenol T 3110 000)
Pin Description
1Neutral
2 Not connected
3 Active
Protective earth
NOTE
The supplied cable has a free end. Terminate a suitable AC mains plug for
your region or country.
