Parts List & Exploded View

Ref No. Description Part No. Qty. Part No. Qty.

1 #6 x ½" SMS, pan head T02797 8 T02797 8

2 Hole plug T05431 1 T05431 1

3 End cap T05428 2 T05428 2

4 End cap gasket T05429 2 T05429 2

5 Aluminum extrusion S81147 1 S81147 1

6 .100 dia. rope gasket T07005 2 T07005 2

7 Lighthead Lens T05425 1 T05425 1

8 Small lighthead optic filter T02354 10 T02344 8

9 Lamp bracket S95863 1 T08685 1

10 ArrowStik

reflector T05526 10 T05526 8

11 #1156 27 watt incandescent lamp T01538 10 T01538 8

12 Lampholder & Bracket T05322 10 T05322 8

13 ArrowStik Jumper-Green T09314 5 T09314 3

14 ArrowStik Jumper-Green/Black T09315 8 T09315 10

15 Cable T05438 1 T05438 1

Cable - 50ft T04485 1 T04485 1

Cable - 70ft T04486 1 T04486 1

16 Strain relief bushing T05861 1 T05861 1

AS-10 AS-847

AS-839

Part No. Qty.

T02797 8

T05431 1

T05428 2

T05429 2

S82552 1

T07005 2

T09094 1

T02344 8

S95922 1

T05526 8

T01538 8

T05322 8

T09314 3

T09315 6

T05438 1

T04485 1

T04486 1

T05861 1
