Code 3 FM100C User Manual

6
5
6
7
8
FIGURE 3
9
3
4
Top edge of bracket
must be opposite of
drain holes.
Do not
leave any
slack in
speaker
wires
during
assembly.
All drain holes
must be
alligned on the
lower end of
speaker
bracket.
Parts & Exploded Views
Parts Shown in Fig. 2
1 Coated Mounting Bracket S35470
2 Trim Bezel T03776
Ref Number Description Part No.
3 Speaker wire Assemblies T04346 & T04347
4 Speaker Screws T06519
5 Speaker Horn S85477
6 Driver Cover T03739
7 100w Siren Driver T03470
8 Driver Cap S85478
9 Nose Cone Screw T09204
Ref Number Description Part No.
Self Tapping
(Thread Clearing)
