Code 3 XCEL Series Installation And Operation Instructions

Page 6 of 12
Congurable Features for L6 Models
Dip Switch UP Dip Switch DOWN
Dip Switch 1 California Title 13 ON California Title 13 OFF
Dip Switch 2 Hands Free w/ Level 3 Lighting ON Hands Free w/ Level 3 Lighting OFF
Dip Switch 3 Hands Free ON Hands Free OFF
Dip Switch 4 Siren Lock ON Siren Lock OFF
Dip Switch 5 Horn Ring Transfer Always Enabled Horn Ring Transfer on Dip 8 Setting Only
Dip Switch 6 Scroll has “OFF” step Scroll does not have “OFF’ step
Dip Switch 7 Hit-N-Go Scroll
Dip Switch 8 Horn Ring Transfer Level 3 Only Horn Ring Transfer in Level 2 & 3
Dip Switch 9 No Function No Function
Dip Switch 12 Alt. Tone set as Hyper-Yelp Alt. Tone set as Hi-Lo
Dip 10 + Dip 11 Dip 10 UP, Dip 11 UP, 3 Level Switch is Progressive Dip 10 DOWN, Dip 11 DOWN, 3 Level Switch is Progressive
Dip 10 + Dip 11 Dip 10 UP, Dip 11 DOWN, 3 Level Switch is Indepenent Dip 10 DOWN, Dip 11 UP, 3 Level Switch is Semi-Progressive
Congurable Features for Non-Light Control Models
DIP SWITCH FUNCTION DESCRIPTION
DIP
SWITCH
NO./
POSITION
DIP3
DIP4 DIP5 DIP6 DIP7 DIP8 DIP 9 DIP10 DIP11 DIP12
UP
Park
Kill+12V
Horn Ring
+12V
Button
Press
Beep
Scroll has
“OFF” Step
Hit-N-Go N.C N.C. N.C. N.C.
Hyper-
Yelp
DOWN
Park Kill
GND
Horn Ring
GND
Button
Press
No Beep
Scroll has
No “OFF”
Step
Scroll N.C. N.C. N.C. N.C. Hi-Lo
Amplier Power Distribution
The Level 1, 2, 3A and 3B outputs can supply a maximum of 15 Amps each or a combined total of 50 Amps. Each Level has a
20 Amp fuse installed inside the Amplier. Fuses may be accessed through the panel on top of the Amplier.
The Auxiliary outputs A, B, C, D, E, and F can supply a maximum of 10 amps each or a combined total of 60A. Auxiliary out-
puts A, B, C, D, E, and F have 15 amp fuses. Fuses may be accessed through the panel on top of the Amplier.
WARNING!
Connection of a 58 watt speaker to the siren amplier will cause the speaker to burn out, and will void the speaker warranty!
WARNING!
Any electronic device may create or be a󰀨ected by electromagnetic interference. After installation of any electronic device, operate all
equipment simultaneously to insure that operation is free of interference.
WARNING!
Utilizing non-factory specied screws and/or mounting brackets and/or the improper number of screws may result in failure of the
mounting system and severe damage to the vehicle as well as loss of warranty coverage on the equipment.
DIP1
DIP2
Function
DOWN
DOWN
Backlight
Level 1
DOWN UP
Backlight
Level 2
UP DOWN
Backlight
Level 3
UP UP
Backlight
Level 4
Note: If any Dip Switches are modied while powered on, Power must be reset to entire unit for Dip Switch setting to take e󰀨ect
