7
2. 18 PIN HARNESS, CONTINUED
Instant Trigger (-) (BLUE/WHITE)
This wire is a GROUND input for an external sensor or secondary pin switch.
Verification: This wire when connected will trigger the security system
External Start Trigger (-) (WHITE/BLUE
This wire will activate the Remote Start when a GROUND pulse is applied to it from an external device
Active Output (-) 300mA (BLUE/BLACK)
The Active Output/Ignition 3 output wire provides a ground output when the remote start function is activated
and remains active 4 seconds after the remote start is shutdown. The Ignition 3 output wire can be used
for several functions. If this wire will be used for multiple applications a 1 amp diode is required in-line
with the stripe facing the control module.
Illuminated Entry Output (-) 300mA (BLACK/WHITE)
This wire provides a 300mA output for 30 seconds when the system is disarmed and a continuous output
when the system is triggered.
Locate the vehicle’s dome light or pin switch wire.
Verification: This wire will register positive voltage or ground when the vehicle's dome light is turned ON.
Low Current Horn Output (-) 300mA (BROWN/BLACK)
Locate the vehicle’s horn wire at the steering column.
Verification: This wire will rest at positive voltage and register ground when the horn switch is pressed.
Connect the BROWN/BLACK wire to the vehicle’s horn wire.
