Code Gobo 200 User Manual

English Manual
- 2 -
Connecting to scanner
According to DMX512 protocol, DMX signal cable must be screened twist cable with impedance of 120Ω. In
practical engineering installation, if the whole length of the cable is short, the cable may be replaced by high
quality screened two-core microphone cable.
User joins each end of the cable to a XLR plug. Foot 1of the XLR plug is connected to the screen net of the
cable. Twist lines (distinguished by different colors) are connected to foot 2 and 3. Foot 3 is signal + and foot 2
is signal -. Foot 2 and foot 3 of the plug cannot be confused.
To ensure correct DMX signal transmission, an 120Ω terminal matching resistance must be connected to the
last equipment to absorb terminal signal reflection. The operation is as following: connect a 120Ω resistance
to foot 2 and foot 3 of a plug then plug it to the output of the last scanner (or other equipment).
Address distribution of DMX512
GOBO 200 scanner controller utilizes channel 1-96 of DMX512 to transmit the control signals to various
scanners. Each scanner is fixed with 8 control channels.
First DMX address of scanner
Scanner No.
Decimal Code
Switch bit of scanner address
123456789
1 1 100000000
2 13 101100000
3 25 100110000
4 37 101001000
5 49 100011000
6 61 101111000
7 73 101100100
8 85 101010100
9 97 100001100
10 109 101101100
11 121 100111100
12 133 101000010
13 145 100010010
14 157 101110010
15 169 100101010
16 181 101011010
DMX ch.
1#scanner
112
2#scanner
13 24
3#scanner
25 36
16#scanner
181 192
15#scanner
169
180
12 ch.scanner x 16
