Schematic of system connection
GOBO 200
Scanner Console
120Ω
Resistance
1#
scanner
DMX addr:
1
2#
13
3#
25
4#
：37
16#
181
12 ch. Scanner x 16
DMX Cable
DMX addr:
DMX addr:
DMX addr:
DMX addr:
scanner
scanner
scanner
scanner
