Code H1 User Manual

H1 / H3 / H4 / H7 (REMOVABLE SOCKET)
Voltage: 12V DC
Working Voltage: 12V~14.2V DC
Consumption: 24W Per Lamp
Color Temperature: 6000K
Metal Lamp Base
Lumens: 4400 Lm (Each)
Number of LEDs per Lamp: 2
LED Type: CSP FLIP
Certification: IP67 (water resistant)
heat resistant
Configurations: With external reactor
TECHNICAL INFORMATION
Rotate or pull the socket.
INSTALLATION
Pull it up and carefully
remove it.
21
Install and fix the socket to the
headlight. Use exactly the socket
specified in the vehicle manual.
3
Insert the lamp body in the
direction shown by the arrow.
4
Turn the bulb clockwise until
the Ultra Led locks or fix
correctly. Each model has its
characteristic.
5
Plug the power outlet with the
car original lamp connector.
6
After all the step by step, don't forget to close the client's light to protect it from
water and dust. The entire process must be carried out by a trained professional.
3
Merely illustrative images.
Merely illustrative images.

Code H1 Specifications

General

Brand	Code
Model	H1
Category	Automobile Accessories
Language	English
