7.
7. INSTALLATION AND START - Tower for wall-mounting
7.3 Mounting of wall console for wall-mounted Tower.
INSTALLATION INSTRUCTIONS
INSTALLATION ON CONCRETE OR STONE WALL:
1. Mark and drill holes. The holes should be large enough for a wall plug and screw.
2. Place the wall plug in the holes and use the screws to screw the wall console to the wall
INSTALLATION ON WOODEN WALL:
1. Mark and drill holes.
2. Screw the wall console to the wall with the appropriate screws.
90°
90°
