3
1
3
5
2
4
6
Legend*
1 = VGA Cable
2 = RJ-45 LAN Cable
3 = Touch Screen
Cable
4 = USB Cable
5 = Power Connector
6 = Ethernet Cables
*The legend numbers also
correspond with the numbered
Installation steps.
