4
1
Connect the VGA Cable
Connect a VGA cable to VisionView VGA’s VGA port, and connect the other
end of the cable to a monitor or a touch screen’s VGA port.
VisionView VGA Support
VisionView software instructions are presented in detail in the VisionView
®
Software
Manual, which is included on the VisionView CD and available for download from the
VisionView support site: www.cognex.com/Support/VisionView.
Installation
Note: Cables are sold separately. If any of the contents appear to be missing or
damaged, immediately contact your Cognex Authorized Service Provider (ASP) or
Cognex Technical Support.
2
Connect the Network Cable
Connect an RJ-45 cable to VisionView VGA’s LAN port, and connect the other
end of the cable to a switch/router, as applicable.
Notes:
A Cognex vision sensor can be directly connected to VisionView VGA •
LAN port.
The VisionView VGA LAN port does not provide Power over Ethernet•
(PoE) to Cognex sensors.
