5
3
Connect the Touch Screen Cable
(Optional)
If connecting a touch screen to VisionView VGA, connect the Touch1.
Screen cable’s RJ-12 connector to VisionView VGA’s Touch Screen port.
Connect the other end of the Touch Screen cable to the touch screen’s2.
serial connector.
4
Connect the USB Accessories (Optional)
If connecting a USB mouse or keyboard to the VisionView VGA, connect a
USB cable to VisionView VGA’s USB port.
5
Connect the Power Cable
Verify the 24VDC power supply being used is unplugged and not1.
receiving power.
Attach the power cable’s -24V wire to Pin 2 and the +24V wire to Pin 32.
on the green power connector supplied with VisionView VGA. Connect a
frame ground wire from Pin 1 to frame ground. Tighten the wire retention
screws.
Insert the green connector into the Power Connector port and tighten the3.
connector screws.
Caution: Do not connect AC power directly to the VisionView VGA
Power Connector.
Restore power to the 24VDC power supply and turn it on if necessary.4.
