Coleman 5600 Series User Manual

ÖÖ
Assemble the Electrode
Wire to the Electrode Tip
on the Side Fryer.
ÖÖ
Assemble the Grease Pan
below the Fryer Burner.
Step
14
14-A
14-A. Attach the Electrode Wire to the Electrode Tip on the Side Fryer.
Electrode Tip
Route the Electrode Wire
through the slot in the
Fryer Panel.
Left
Side
Panel
14-B
14-B. Attach Fryer Grease Pan using four hooks located below the Fryer Burner.
ÖÖ
NOTE: To attach the Fryer Grease Pan, raise the Pan slightly above the
hooks and drop into place. Do not bend the hooks while inserting or
removing the Fryer Grease Pan.
Fryer
Grease Pan
Hooks
19
Electrode Wire
Fryer
Panel
