Assemble the electrode
Wires and the Battery to
the Electrode Module.
Step
17
17-A
Electrode Module
Igniter Button Wires
(Note: Large Tabs)
9-Volt Battery
TEST THE IGNITER:
A SPARK SHOULD APPEAR AT
ELECTRODE TIP
.
IF THE SPARK DOES NOT
APPEAR
:
-C
HECK THE WIRE
CONNECTIONS TO THE
MODULE
.
-C
HECK PROPER
ASSEMBLY OF FRESH
9-VOLT BATTERY.
Back Burner
Electrode Wire
17-A. Firmly push the Electrode Wires into the Electrode Module.
ÖÖ
Assemble the 9-Volt Battery to the Electrode Module.
ÖÖ
NOTE: The polarity is marked on the Electrode Module.
22
