Coleman BK200 - Brush Guard and Bumper Assembly

BRUSH GUARD, BUMPER
Hardware:
M8 x 55 Bolts (1)
M8 x 15 Bolts (2)
M8 Concave Washers (3)
M8 Lock Nuts (4)
1
2
3
4
NOTICE: FOR EASE OF
ASSEMBLY, DO NOT TIGHTEN
ANY BOLTS UNTIL ALL PARTS
ARE IN PLACE
1. Install center brush guard
support (A) Use bolts (1)
Concave washers (4) and lock
nuts (3)
2. Install front brush
guard supports (B). Use
bolts (1) Concave wash-
ers (4) and lock nuts (3)
A
B
(1)
(4)
(3)
(1)
(4)
(3)
(1)
(4)
4
