(V) STOPPING THE ENGINE
1. Before stopping engine, turn off electrical device being
powered and unplug it from
the generator. See Picture
14.
2. Turn the engine switch to “STOP”, see Picture 15.
3. Turn the fuel petcock to “OFF”, see
picture 16.
-12-
z Generator Troubleshooting
Problem Possible Cause Corrective Action
Indicator light ON
No AC output
Tripped circuit breaker Reset
Poor connection or faulty
lead
Check and repair
Broken receptacle Check and repair
Faulty circuit breaker Check and repair
Indicator light OFF
No AC output
Generator problem Check and repair
Indicator light OFF
No DC out put
Tripped circuit breaker Reset
Poor connection or faulty
DC power cord
Check and repair
Generator problem Consult dealer
Output power
available
abnormality exists
Engine RPM set too high
or low
No load for 60HZ
Set 3780rpm
Loose component Locate and tighten
Internal generator
problem
Consult dealer
DC APPLICATION: The DC terminals of the generator
may be used for charging 12-volt automotive batteries only.
Connect the charging cables to the
terminals of the generator as shown.
Be sure to observe the correct polarity!
(Picture 16)
-17-
