Coleman CM04101 User Manual

TABLE OF CONTENTS
SAFETY GUIDELINES&INFORMATION --------------- 2~7
PRE-OPERATION PREPARATION ------------ 8
STARTING THE ENGINE -------------------- 9 thru 10
CONNECTION -----------------------------------------------11
STOPPING THE ENGINE -----------------------------12
PERIODIC MAINTENANCE -----------------13 thru15
TROUBLESHOOTING ------------------------16 thru 17
DC APPLICATION -----------------------------------------17
EXPLODED VIEW - GENERATOR-----------------18
PARTS LIST - GENERATOR --------------------------19
EXPLODED VIEW - Control Panel ----------------20
PARTS LIST - Control Panel ------------------------- 21
SCHEMATIC
--------------------------------------------------22
APPLICABILITY
---------------------------------------------23
WARRANTY----------------------------------------------------24
(X) APPLICABILITY
MODEL 04101
GENERATOR
Type
Brushless, Revolving Field, Self-exciting,
2-poles, Single phase
Voltage Regulator Condenser Type
Max. Output 1000W
Rated Output 900W
AC Voltage 120V
Rated Current 7.5A
Frequency 60Hz
Phase single
Power Factor cos=1.0
Performance Class G1
ENGINE
Type
Air-cooled 2-stroke, Single Cylinder
Oil-mixed Fuel Engine
Displacement 71cc
Stroke 45×40mm
Max. Output 2.0HP/3600rpm
Fuel Regular Automobile EURO95/98
Oil 2-stroke small engine oil
Fuel/Oil Mix Ratio 40:1
Fuel tank Capacity 1.1 gallon
Starting System Recoil Starter
Ignition system C.D.I
Air Cleaner Type Sponge Element
Certificate EPA
UNIT
Length×Width×Height 16.93* 14.96*14.96 in
Net Weight 36.5lbs
-23-
