Coleman EVEN HEAT User Manual

1
TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (long and short)
• 1/4” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
For correct hardware assembly, always
position the lock washer between the screw
and the flat washer.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
HARDWARE PACK
1/4”-20UNCx38 Screw
X 8
φ7 Lock Washer
X 31
1/4”-20UNC Screw
X 4
1/4”-20UNCx16 Screw
X 23
φ7 Washer
X 33
NO.10-24UNCx13 Screw
X 29
1/4” Nut
X 8
φ7 Fiber Washer
X 8
NO.8-32UNCx10 Screw
X 9
φ5 Lock Washer
X 29
φ5 Washer
X 29
1
2
3
4 5
6
7
8 9
10
11 12
13
16
14 15
U Pin
X 1
Screw for Vent
X 2
Cotter Pin
X 1
NO.10-24UNC Nut
X 2
ST4.2X10 Tapping Screw
X 2
No. Description Part Number Qty.
1 1/4"-20UNCx38 Screw 20120-13038-250 8
2 1/4"-20UNCx16 Screw 20120-13016-250 23
3 1/4" Nut 30220-13000-250 8
4 φ7 Lock Washer 41400-07000-250 31
5 φ7 Washer 40300-07000-250 33
6 φ7 Fiber Washer G501-0054-9100 8
7 NO.10-24UNCx13 Screw 20124-10013-250 29
8 NO.8-32UNCx10 Screw 20132-08010-250 9
9 1/4"-20UNC Screw G353-0014-9000 4
10 φ5 Lock Washer 41400-05000-250 29
11 φ5 Washer 40300-05000-250 29
12 ST4.2X10 Tapping Screw 22500-42010-137 2
13 U Pin G350-0026-9000 1
14 Screw for Vent G411-0040-9100 2
15 NO.10-24UNC Nut 33524-10000-037 2
16 Cotter Pin G515-0013-9000 1
17 φ4 Lock Washer 41400-04000-250 1
17
φ4 Lock Washer
X 1
Lock Washer
Flat Washer
Screw
BEFORE ASSEMBLING THE BARBECUE, READ THESE INSTRUCTIONS CAREFULLY.
Assemble the barbecue on a flat, clean surface. Grill is heavy. You should have at least two
people assemble the barbecue together.
