PARTS LIST (PROPANE) FOR 85-3076-0 (G53103)
Item No. Qty. Description Part No.
AA 1 Top lid assembly, charcoal side G531-2000-01
AB 2 Thermometer G522-0062-01
AC 2 Screw for top lid, charcoal side G354-0025-01
AD 2 Lid bumper, front, charcoal
side
G522-0088-01
AE 2 Lid bumper, rear, charcoal side G501-0066-01
AF 1 Top lid assembly, gas side G531-4000-01
AG 2 Screw for top lid, gas side G354-0025-01
AH 2 Lid bumper, front, gas side G522-0088-01
AI 2 Lid bumper, rear, gas side G501-0066-01
AJ 1 Top lid vent G531-0001-01
BA 1 Burner box assembly, charcoal
side
G531-3500-01
BB1 1 Burner box side vent G531-0054-01
BB2 1 Lever (side vent) G531-0055-01
BB3 1 Handle (side vent) G531-0056-01
BC 1 Charcoal grate assembly G531-7000-01
BD 1 Cooking grate removal tool G531-0046-01
BE 1 Crank mount G531-0014-01
BF 1 Crank arm G531-2700-02
BG 1 Crank bezel G531-0030-01
BH 2 Cooking grate, charcoal side G522-0091-01
BI 1 Warming rack, charcoal side G531-0058-01
BJ 1 Burner box assembly, gas side G531-8000-01
BK 3 Even Heat™ burners G522-B600-01
BL 1 Carryover assembly G522-0087-02
BM 3 Even Heat™ heat distribution
plate
G522-0072-01
BN 3 Dual surface cooking grate G522-0097-01
BO 1 Warming rack, gas side G531-0059-01
BP 1 Match holder G608-0019-01
BQ 2 Even Heat™ heat distribution
plate brace
G522-0085-01
CA 1 Manifold assembly - LP G531-2100-01
CB 1 Regulator G409-0069-01
CC 3 Control knob G522-B700-01
CD1 1 Electronic ignition assembly G522-00A5-02
CD2 1 Electronic ignition battery cap G515-0030-01
CD3 1 InstaStart™ ignition button G353-0009-01
CE 3 Electrode set, main burner G522-0020-01
CF 1 Control panel G531-0057-01
CG 1 Front brace G531-0027-01
CH 1 Quick Clean™ grease tray G522-7500-01
CI 1 Quick Clean™ grease cup G416-0015-01
CJ 1 Door support rail G531-2200-01
CK 1 Heat shield G531-0053-01
Item No. Qty. Description Part No.
CL 1 Left track G522-0027-01
CM 1 Right track G522-0043-01
CN 1 Upper back panel G531-0028-01
CO 1 Ash funnel G531-0045-01
CP 1 Ash collection tray G531-0031-01
DA 2 Support bracket A, side shelf G353-1400-01
DB 2 Support bracket B, side shelf G353-1500-01
DC 2 Side shelf G353-4300-01
EA 1 Cart side panel - left G531-0800-01
EB 1 Cart side panel - right G531-1700-01
EC 1 Bottom shelf - LP G531-3700-01
ED 2 Locking castor G350-0023-01
EE 2 Castor G350-0024-01
EF 1 Left door assembly G531-2500-01
EG 1 Right door assembly G531-2600-01
EH 1 Middle panel assembly G531-0025-01
EI 2 Door handle, door assembly G531-0034-01
EJ 1 Door handle, middle panel G531-0026-01
EK 1 Interior cart divider G531-0024-01
EL 2 Door magnet assembly G501-00F2-02
EM 2 Tank exclusion wire G522-0092-01
F1 1 Hardware pack G531-B003-01
F2 1 Assembly manual G531-M003-01
F3 1 Safe use and care manual G353-M005-02
F4 1 Charcoal grill cooking guide G531-M003-02
F5 1 Tank screw G505-0047-01
