PEDESTAL FIXING Fig.1
EN60335-2-41 TEST standard requires the filter pump must be vertically fixed on
ground or a certain pedestal made of wood or concrete before use. There should
be two holes 9mm in diameter on the pedestal, the space between which should
be 163mm. Put filter pump on the pedestal and fix them together by fasten the
bolts and nuts. All the pedestal parts should weigh over 18kgs at least to prevent
the pump from accidental falling.
