7
CEILING ASSEMBLY PATCH CORD
ROOM TEMPERATURE SENSOR
TOP SIDE OF CEILING SHROUD
CEILING ASSEMBLY
SHROUD
CEILING ASSEMBLY
GRILLES
CEILING ASSEMBLY
FILTERS
This concludes the installation of the system. The following
pages contain the operating and maintenance instructions.
FIGURE 6
