1. Layout Drawings
1.1 Machine components
Machine components
1. Machine legs 5. Manual door release
2. Sliding door 8. Control panel CSE
3. Main switch and main fuse 7. Lower clamping plate
4. Emergency Stop 8. Locking lever
2
3
4
5
7
6
8
1
