Collomix VISCO 550 - 1 Layout Drawings; Machine Components

VISCO 550 Collomix GmbH
4 Version 1.1-17
1. Layout Drawings
1.1 Machine components
Machine components
1. Machine legs 5. Manual door release
2. Sliding door 8. Control panel CSE
3. Main switch and DC fuse 7. Lower clamping plate
4. Emergency Stop 8. Locking lever
2
4
5
3
1
6
7
8
