Colorful B365M-PLUS V21 - Clear CMOS Jumper and Procedure; Clear CMOS Procedure

Clear CMOS Jumper: CLR_CMOS
There is a CMOS RAM on board that has a power supply from
external battery to keep the system configuration data. With the
CMOS RAM, the system can automatically boot OS every time it
is turned on. If you want to clear the system configuration, use
the CLR_CMOS Jumper to clear data.
Clear CMOS PROCEDURE
You can clear CMOS by shorting 2-3 pin. Before you clearing the
CMOS, following next procedure:
1ㄋTurn off the AC power supply and connect pins 2 and 3
together using the jumper cap.
2ㄋReturn the jumper setting to normal (pin 1 or 2) or Remove the
jumper cap
3ㄋTurn the AC power supply back on.
Clear CMOS settings
1or2 normal
1-2 clear CMOS
41
Ｈａｒｄｗａｒｅ Ｉｎｓｔａｌｌａｔｉｏｎ
