GRAVITY
Changing
the
Center Of Gravity (Eclipse,Lil
Dipper,)
The Center Of Gravity
is
changed by moving
the
rear
axle
position forward
or
back.
The following
steps are
how
it is done:
1.
Push
the
Rear Wheel Quick Release button. (Refer
to
"Quick
Releases"
on
page
16.)
2.Remove
the
rear
wheel.
3.Loosen
the
large
nut on the
inside
of the axle
plate/camber
plate.
Once
the nut is
loosened enough
to
free
the
guiding pin
on the out-
side
of the axle plate,
move
the axle
receiver forward
(to
allow
the
chair
to tip
more)
or to the
rear
(to
make
the
chair
tip less).
4.Place
the
guiding pin
in
desired hole
and re-tighten the nut on the in-
side
of the axle plate.
Make
sure the
guiding pin
is
completely
posi-
tioned
in one of the axle plate's
holes before you
tighten the nut.
5.Reinstall
t
he
rear
wheel.
6.Repeat
steps
1
thru 6 on the other
rear axle.
(note:
The
axles
must
be
set in the same
position
on both the
right
and the left
side
of your
chair.
Once
you
have determined your
axle
position,
it
is
ex-
tremely importan
t
that the
axle receiver
is securely
fastened
on the axle
plate
,
by tightening
the large
nuts that
you released
to
move
the
axles
.
There
should
be no
play
in the
axle
assembly.
Changing
the
Center Of Gravity (Suspesion and Super
tube style
)
Because
the shape of the
frame
on some
models
are slightly
d
i
fferent
adjusting
the
COG
is
accomplished by
the
following
steps:
1.
Push
the
Rear Wheel Quick Release
button.
(Refer
to
"Quick Releases"
on
page
16.)
2.Remove
the
rear
wheel.
3.Using
an
Allen wrench, remove
the all
bolts
securing
the suspension mount or
axle
plate to the frame on each side of the wheel-
chair.
4.S
l
ide
the
suspension mount
or
Axle
plate
forward
or
back
to
the
desired
setting.
5.
R
e
install
the
bolts
on each
side
of the
wheelchair
.
.................................................
3
..
.
..................
..
........
4
6
OWNER
'S MANUAL
4
.........
....................
.
....
..
....
......
0
0
0
oO
D
O
...
..
.
..
.
.
.
.
...
Axle
Plate (super
tube
)
0
