Printed In USA
OPERATORS MANUAL
4BGF0QFSBUJPO1SBDUJDFTt4FU6Qt0QFSBUJPOt.BJOUFOBODFt4FSWJDFt5SPVCMFTIPPUJOHt8BSSBOUZ
8"3/*/(
3&"%"/%'0--08"--4"'&5:36-&4"/%*/4536$5*0/4*/5)*4."/6"-
#&'03&"55&.15*/(5001&3"5&5)*4."$)*/&
'"*-63&50$0.1-:8*5)5)&4&*/4536$5*0/4.":3&46-5*/1&340/"-*/+63:
3;54FSJFT5SBDUPS.PEFM;5;5
LES DISTRIBUTIONS RVI LIMITÉE, 2955, JEAN-BAPTISTE DESCHAMPS, LACHINE, QUEBEC H8T 1C5
MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
769-04725A
(01.14.10)

Questions and Answers

  • A
    ashley02Aug 13, 2025
    Why Columbia ZT42 engine fails to start?
    • J
      jamesgreenAug 14, 2025
      Your Columbia Lawn Mower engine might fail to start due to several reasons. It could be because the PTO/Blade Engage knob is engaged (place it in the disengaged/OFF position), the parking brake isn't engaged (engage it), or the drive control levers aren't fully outward in the neutral position (move them fully outward). Other potential causes include disconnected spark plug wires (connect them), incorrect throttle/choke control lever position (place in choke position), an empty or stale fuel tank (fill with fresh gas), a blocked fuel line (clean and replace fuel filter), faulty spark plugs (clean, adjust gap, or replace), or a flooded engine (crank with throttle in FAST position).
  • J
    Joshua LeeAug 17, 2025
    Why Columbia Lawn Mower engine runs erratic?
    • K
      Kerri ChurchAug 17, 2025
      An erratic running Columbia Lawn Mower engine can stem from several causes. Check if the tractor is running with the CHOKE activated and pull the throttle/choke control lever rearward from the choke position. Loose spark plug wires can also be the culprit, so ensure they are connected. Other potential issues include a blocked fuel line or stale fuel (clean the fuel line, replace fuel filter, and use fresh gasoline), a plugged vent in the gas cap (clear the vent or replace the cap), water or dirt in the fuel system (drain and refill with fresh gasoline), or a dirty air cleaner (replace the air cleaner element).
  • S
    scottmartinAug 21, 2025
    What to do if Columbia ZT42 Lawn Mower is not mulching grass?
    • D
      David Harrington PhDAug 21, 2025
      If your Columbia Lawn Mower isn't mulching grass effectively (assuming it has a mulching kit), there are a few things to consider. First, ensure the engine speed isn't too low by placing the throttle/choke control lever in the FAST position. Avoid mulching when the grass is wet. If the grass is excessively high, mow once at a high cutting height, then mow again at your desired height, or try making a narrower cutting swath. Finally, check if the blade is dull and sharpen or replace it if needed.
  • M
    Matthew SmithAug 25, 2025
    Why Columbia Lawn Mower engine overheats?
    • W
      William RobinsonAug 25, 2025
      If your Columbia Lawn Mower engine is overheating, it could be due to a low engine oil level, so fill the crankcase with the correct amount and weight of oil. Another cause could be restricted airflow; clean any grass clippings and debris from around the engine’s cooling fins and blower housing.
  • D
    Daniel BrooksAug 28, 2025
    Why Columbia Lawn Mower has an uneven cut?
    • T
      tyoungAug 28, 2025
      An uneven cut with your Columbia Lawn Mower can result from a few things: the deck may not be leveled properly (perform a side-to-side deck adjustment), the blade might be dull (sharpen or replace it), or the tire pressure could be uneven (check the tire pressure in all four tires).
  • K
    Kristy LewisSep 1, 2025
    What causes excessive vibration in Columbia ZT42?
    • A
      Alexander MyersSep 1, 2025
      Excessive vibration in your Columbia Lawn Mower is often due to a loose or unbalanced cutting blade (tighten the blade and spindle) or a damaged or bent cutting blade (replace the blade).
  • T
    Teresa Thomas MDSep 4, 2025
    Why Columbia ZT42 engine idles rough?
    • S
      Scott MitchellSep 4, 2025
      A rough idling Columbia Lawn Mower engine can be caused by spark plugs that are fouled, faulty, or have a gap that's too wide; replace the spark plugs and set the correct plug gap. Another potential cause is a dirty air cleaner; replace the air cleaner element and/or clean the pre-cleaner.
  • M
    Michael RussellSep 8, 2025
    Why Columbia ZT42 Lawn Mower engine hesitates at high RPM?
    • S
      Sara EvansSep 8, 2025
      If your Columbia Lawn Mower engine hesitates at high RPM, the spark plug gap may be too close. Remove the spark plug(s) and reset the gap.

Summary

Safe Operation Practices

General Operation

Read, understand, and follow all instructions before operating.

Slope Operation

Guidelines for safe operation on slopes to prevent tip-overs.

Assembly & Set-Up

Controls and Features

Ignition Switch

Explanation of the ignition switch positions and safe operation.

Throttle;Choke Control

How to adjust engine speed and use the choke for starting.

Operation

Before Operating Your Tractor

Pre-operation checks and familiarization with controls.

Starting the Engine

Step-by-step guide to safely start the tractor engine.

Maintenance & Adjustments

Troubleshooting

Engine fails to start

Common causes and remedies for engine starting issues.

Columbia ZT42 Specifications

General IconGeneral
Cutting Width42 inches
Deck MaterialSteel
TransmissionHydrostatic
Fuel Tank Capacity3 gallons
Cutting Height1.5 - 4 in
Fuel Capacity3 gallons
