IGL-RA15 2.0.0 Global Guide
6
2 System overview
2.1 Controller type settings 6
2.2 Controller address setting 6
2.3 LEDs color change 7
2.4 Horn timeout setting 7
2.5 Signal LEDs 7
2.6 Horn 8
2.7 Lamp and horn test 8
2.8 LED labels 8
6 back to Table of contents
2.1 Controller type settings
Controller type Jumper A Jumper B Address
InteliCompact-NT
InteliLite-NT
InteliDrive Lite
OPEN OPEN 1
InteliGen-NT
InteliSys-NT
InteliDriveDCU
InteliLite(IL3)
CLOSED OPEN 5+6
InteliGen-NT
InteliSys-NT
InteliDriveDCU
InteliLite(IL3)
CLOSED CLOSED user defined
2.2 Controller address setting
SW changing of CAN1 address is enabled only when both jumpers are closed. Any one of these addresses (1+2
or 3+4 or 5+6 or 7+8) can be set by following steps:
Switch to programming mode (Hold the Horn reset and Lamp test when unit is powering on)
Status led is yellow
Press Lamp test sixteen times
Set the address up by pressing Horn reset.
The number of red luminous LEDs means the CAN1 addresses (two for addresses 1+2, four for
addresses 3+4, six for addresses 5+6 and eight for addresses 7+8)
Press Lamp test
