Combi-Camp Trailer - Technical Data; Country Model Dimensions; Valley Model Dimensions; 7 Pin Plug Wiring

17
Tekniske oplysninger
Fitting instructioN fo r 7 Pi n pl ug (1 2N ) or 13 P in p lu g
1.Yellow-Lefthandindicator
2.Blueheavycable-Fridge
3.White/black-Earth
4.Green-Righthandindicator
5.Brown-Righthandsidelight
6.Red-Brakelight
7.Black-Lefthandsidelight
Orange and thin blue (fog light).
Not in use.
1.Yellow-Lefthandindicator
2.Bluethin-Foglight
3.White-Earth
4.Green-Righthandindicator
5.Brown-Righthandsidelight
6.Red-Brakelight
7.Black-Lefthandsidelight
9.Blueheavycable-Fridge(+)
13.Blue/White-Fridgeearth.
Orange not used.
Netweight: 350kg
withoverrunningbrakes: 375kg
Cross weight: 750 kg
Netweight: 450kg
Gross weight: 750 kg
technical data
UK
All dimensions i mm
1
8
6
11
12
13
10
9
7
5
2
4
3
1110
Valley
Valley
539
4160
3051
1998
1692
1258
1260
2900
2450
420
1130
539
4160
3372
1998
1692
1250
1270
2700
420
2450
335
CountryVALLY
