•Hereafterthefrontsectionofthe
 frameisattached(fig.6)Nowthe
 frameisadjustedsothatthecan-
 vasisniceandtight.
•Theheightis
adjustedonthe
twolegs.Adjust
theintegrated
framesandlock
theblack
adjuster(Fig.7)
•Thesidecan
 nowbepegged
 orrolledback
 tothetrailer.
•Suncanopy
 fullyerected.
Erection of integrated,
sun canopy/awning
Theframesystemis
showninFig.6
•Thebodycanvasisloweredbyuse
 ofthetwothumbscrews,sothat
 allforceisreducedfromthetent
 canvasand
 theintegra-
 tedframes
 canmove
 freely.
 Thecanvas
 isnowzip-
 pedontotheCOMBI-CAMP
•Thesun
 canopyis
 puton
 topofthe
 integrated
 frames,
 whilst
 theyarepulledout.Boththe
 frames22mmand19mm
 arepulledout,
 suchasthelittle
 pressurespring
 isengagedinto
the22mm
 frameandthisis
 pulledout¾way.
Integrated sun canopy/awning
Fig.6
Fig.7
