Comcast 781W - Technical Parameter

6
781W
1.3 Technical Parameter
Technical items
Descriptions
PON interface
1 G/EPON port(EPON PX20+ and GPON Class B+)
Wavelength:Tx1310nm,Rx 1490nm
SC/UPC or SC/APC connector
Receiving sensitivity: ≤-28dBm
Transmitting optical power: 0~+4dBm
Transmission distance: 20KM
Wavelength
Tx1310nm,Rx 1490nm
Optical interface
SC/UPC or SC/APC connector
Interface
1* 10/100/1000Mbps auto adaptive Ethernet interfaces. Full /Half Duplex,
RJ45 connectors.
Wireless
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R 1 internal antenna,dual
external antenna
Indicator
5 indicators，POWER、LOS、REG、LINK/ACT、SYS
Operating condition
-5℃～55℃，10%～90%（non-condenseing）
Storing condition
-30℃～60℃，10%～90%（non-condenseing）
Power supply
DC 12V,0.5A
Power consumption
≤6W
Dimension
120mm×78mm×30mm（L×W×H）
Net weight
0.13Kg
