P.8
◆
Product Specifications
Frequency Range 1.8 – 500 MHz in 35 range segments
Display Type 1.8 inch TFT Color LCD
RF Output Level 0 dBm (1mW) :HF/VHF , -1dBm(0.8mW): UHF
Measured SWR Range Analog Meter: 1.0 – 6.0; LCD:1.0 – 9.9
Impedance Range 12.5 – 300 Ohms (Analog and LCD)
Resistance Range 10 – 500 Ohms
Reactance Range 0 – 500 Ohms (Absolute Value) 1.8-190 MHz
RF Connectors “M” (“UHF/SO-239”) for HF/VHF,“N-female” for UHF
Operating Temp. 0º - 40º C (32º - 104º F)
Power Sources 6 x Alkaline or NiMH Rechargeable Cells
External Power: +8 to +16V DC
Current Consumption 190 mA or less
Charging Time 15 hours at 12 – 14V DC (trickle charge)
Dimensions 3.5(W) x 7.75(H) x 2.65(D)inch (overall)
Weight 2lbs 2 oz (w/alkaline batteries)
Supplied Accessory External DC Cable (Center pin +/white wire +)
For After-sale Service
●
For questions about this product, contact your dealer or our Technical Support staff
◆
For repairs or in case of shipping damage, consult the dealer from whom this unit was purchased.
■
This unit has a Limited Warranty for a period of one year from the date of purchase by the original purchaser.
Units determined to have manufacturer defects will be repaired or replaced at the discretion of NCG Company.
For warranty inspection, send the unit prepaid to:
NCG Company
Att: Warranty Claims
15036 Sierra Bonita Ln.
Chino, CA 91710-8901
909-393-6133
www.natcommgroup.com
sales@natcommgroup.com
Specifications for this product are subject to change without notice or obligation,
in the interest of ongoing product improvement.
1st edition. Sep 2015
Copyright (C) 2015 COMET CO, LTD. All Rights Reserved.
COMET CO., LTD.
Tsuji 4-18-2, Minami-ku, Saitama-City, Saitama 336-0026 JAPAN
TEL: +81 048-839-3131 , FAX: +81 048-839-3136
URL (Japanese site) : http://www.comet-ant.co.jp
