II. Performance Data
Specifications
Model DV-6000 DV-6000i DV-9000 DV-9000i DV-12000 DV-15000
Line Pull (first layer) 2,722 kg / 6,000 lb 4,082 kg / 9,000 lb
5,443kg / 12,000lb
6,803kg / 15,000lb
Line Speed (first layer, no load)
14.6mpm / 48 fpm 13.4mpm / 44 fpm 8.3mpm / 27fpm
6.9mpm / 22fpm
12V 350 A 440 A 460 A
Amp. Draw
24V
400A 12 volt only
210 A 290 A 340 A
Type Series wound
12V
3,430 w / 4.6 hp 4,175 w / 5.6 hp
Motor
Output
24V
2,685 w / 3.6 hp
12 volt only
1,940 w / 2.6 hp 2,684 w / 3.6 hp
Type 3 stage planetary
Gear Train
Ratio 156:1 156:1 261:1 315:1
Free spool Rotating ring gear
Brake Automatic, full load cone brake
Control
Detachable
solenoid pack
Integrated
solenoid pack
Detachable
solenoid pack
Integrated
solenoid pack
Detachable
Solenoid pack
Type A7 x 19 aircraft galvanized 6 x W(19)
Length 24.4 m / 80 ft 30 m / 100 ft 38 m / 125 ft 27 m / 89 ft
Wire Rope
Size 8 mm / 5/16 in 8 mm / 5/16 in 9.5 mm / 3/8 in
11 mm / 7/16 in
Performance
Model DV-6000 DV-6000i DV-9000 DV-9000i DV-12000 DV-15000
Line pull (kg / lb) 2,722 / 6,000 4,082 / 9,000 5,443 / 12,000
6,803 / 15,000
Line speed (mpm / fpm)
3.1 / 10 2.0 / 6.6 1.2 / 4 0.76 / 2.5
1
st
layer
Rope cap (m / ft) 6.1 / 20 6.1 / 20 6.2 / 20.3 5.3 / 17.4
Line pull (kg / lb) 2,224 / 4,903 3,335 / 7,352 4,561 / 10,056
5,575 / 12,292
Line speed (mpm / fpm)
3.7 / 12.1 2.4 / 7.9 1.43 / 4.7 0.92 / 3.01
2
nd
layer
Rope cap (m / ft) 13.5 / 44.3 13.5 / 44.3 13.6 / 44.6 11.8 / 38.7
Line pull (kg / lb) 1,880 / 4,144 2,820 /6,217 3,926 / 8,657
4,723 / 10,413
Line speed (mpm / fpm)
4.3 / 14.1 2.9 / 9.5 1.67 / 5.47 1.09 / 3.57
3
rd
layer
Rope cap (m / ft) 22.3 / 73.2 22.3 / 73.2 22.1 / 72.5 19.5 / 64
Line pull (kg / lb) 1,628 /3,589 2,442 / 5,383 3,446 / 7,599
4,097 / 9,033
Line speed (mpm / fpm)
5.0 / 16.4 3.3 / 10.8 1.9 / 6.23 1.26 / 4.13
4
th
layer
Rope cap (m / ft) 24.4 / 80 30 / 100 31.9 / 105 27 / 89
Line pull (kg / lb) 3,070 / 6,770
Line speed (mpm / fpm)
2.13 / 6.98
5
th
layer
Rope cap (m / ft) 38 / 125
Line speed and Amp. Draw
At the first layer of wire rope on the drum.
Model DV-6000/DV-6000i
DV-9000/DV-9000i DV-12000 DV-15000
Line Pull Line Speed
Amp.
Line Speed
Amp. Line Speed
Amp. Line Speed
Amp.
Kg lb mpm
fpm
12V mpm
fpm
12V
24V
mpm
fpm
12V
24V
mpm
fpm
12V
24V
0 0 14.6
48
60 13.4
44
55
30
8.3
27
60
50
6.9
22
60
50
907
2,000
7 23
170 4.6
15
110
65
* * * * * * * *
1,814
4,000
4 13
320 3.4
11
200
100
2.6
8.6
200
100
1.6
5.4
180
90
2,722
6,000
3.1
10
400 2.7
9 230
130
* * * * * * * *
3,629
8,000
* * * 2.3
7.5
260
170
1.7
5.8
310
190
1.2
3.8
280
190
4,082
9,000
* * * 2.0
6.4
350
210
* * * * * * * *
4,535
10,000
* * * * * * * 1.4
4.4
370
230
1.0
3.3
330
220
5,443
12,000
* * * * * * * 1.2
4.0
440
290
0.9
2.9
385
260
6,805
15,000
* * * * * * * * * * * 0.8
2.5
460
340
