Comfee Smart Cool 7000-1 User Manual


Page 15

Installation
Instructions
Step Three: Preparing the Adjustable Window Slider
1. Choose the window sliders according the size of
your window. Sometimes, it needs to be cut short
to meet the window size, please take extra care to
cut it properly.
2. Use bolts to fasten the window sliders once they
are adjusted to the Proper length.
Window slider A Window slider B
Bolt
Window slider A Window slider B
Window slider C
Bolts
Step Two: Install the Exhaust hose assembly to the unit
Push the Exhaust hose into the airoutlet opening of
the unit along the arrow direction.
MODEL B
MODEL A
MODEL C
1+2：
Bolt
Bolt
Bolt
1+2+3：
1+2：
1+2+3：
Bolt
Bolt
Bolt
1+2+3+4：
Bolt
BoltBolt
1+4：
Bolt
Window Sliders
After assembly
Before assembly
Window Sliders
After assembly
Before assembly
or
EN
