All the illustrations in the manual are for explanation purpose only. Your machine may be slightly dierent.
The actual shape shall prevail. The unit can be controlled by the unit control panel alone or with the remote
controller. This manual does not include Remote Controller Operations, see the <<Remote Controller Instruction>>
packed with the unit for details.
Control panel
Remote signal receptor
Front panel
Caster
Vertical louver control
lever-manual adjustment
(On some models)
NOTE ON ILLUSTRATIONS:
Product overview
Design Notice
In order to ensure the optimal performance of our products, the design specifications of the unit and remote
control are subject to change without prior notice.
Front View
Rear View
Handle
(both sides)
Air filter
upper air intake
Air outlet
Lower air intake
Drain outlet
Bottom tray
drain outlet
model A
