Sliding Window Installation
Insert the window
slider assembly into
the window opening.
If desired, install the security bracket
with 2 screws as shown.
Cut the non-adhesive foam seal C strip to match the height of the
window. Insert the seal between the glass and the window frame to
prevent air and insects from getting into the room.
Step 1: Step 2: Step 3:
NOTE: Once the Exhaust Hose assembly and Adjustable Window Slider are prepared, choose from one
of the following two installation methods.
