Comica BoomX-D - Receiver Installation Guide

1.Work with Camera:
Fix the receiver through the belt clip to the camera's hot shoe mount, then connect the receiver with camera through the 3.5mm
TRS-TRS audio cable; Insert the headphone into the monitoring headphone port for monitoring.
Receiver (RX)
3.5mm TRS-TRS Audio Cable
10
