ComMarker B3 - Page 10

5.Marking test
Place the test engraving material on the machine. Click "Red (F1)", the area shown by the red light is the marking area. Tick
“Default Parameters". Click "Mark (F2)" to start marking.
Parameters
Voltage
110V
Laser Type:
Fiber
Working Area
70mmx70mm/ 110mm x 110mm/ 150mmx150mm/ 175mmx175mm/
200mm x 200mm
Wavelength
1064nm
Marking Speed:
0- 15000mm/min
Accuracy
0.01mm
Graphic Format Supported:
AI/PLT/JPG/DXF.etc
System Supported
Window7/8/10/11
Cooling Type
Air Cooling
Output Power
20w-smart/ 30W/ 50W/ 60W
Laser source
MAX / Raycus / JPT Mopa
Weight (KG):
10.5kg-20w-smart/ 21.5KG-30W
、
50W
、
60W
