5
1) Monitor Installation
2) Standard Height of Monitor
3) Wiring Diagram
3. Installation Method
INTERCAM2CAM1
4
3
2
1
4
3
2
1
4
3
2
1
Interphone
CDV-50A
CAMERA2
CAMERA1
White
Yellow
Blue
Red
White
Yellow
Blue
Red
White
Yellow
Blue
Red
CDV-50A-8p 2006.8.9 9:42 AM 페이지5
