30
CCTV Camera wiring
♠ CCTV CAMERA requires a separate power supply.
♠ Use the proper cable (Coaxial Cable) with appropriate specification for various
distances between the CCTV CAMERA and the videophone.
#① : RED--(VIDEO)
#② : Blue-(GND)
