Commax CMD-404FU - Specification

18
6. Specification
CMD-404FU / CMD-404FUD [Floor Distributor]
Building distributor(CMD-101BU) 6 lines (Polarity), MODUME
VIDEO-PHONE 4 lines (Polarity)
(RJ45 CAT5e Patch Cable)
Voltage
1.
MODUM System building distributor(CMD-404FU(D)) 
CMD-404FU(D) IN (Input)
2.
CMD-404FU(D) OUT(Output)  Upstairs CMD-404FU(D) IN (Expansio
3.
CMD-404FU(D) LINE1,2,3,4  Monitor (MODUM System video phone)
Maximum 300m : Main entrance 
monitor, the distance from each floor
distributor to each monitor is limited by 30m.
(79 floor distributor can be interlocked)
Model
Spec
Transmission type
Wiring Sequence
Wiring distance
CMD-404FU : DC 24V / 80mA (MAX)
CMD-404FUD : DC 24V / 3A (MAX)
