Commax DP-3HP User Manual

6
4. General Function
● For installation of DR-3HP, separate power supply should be required to DRC-nAC/nAB
and DR-3Q is available only for individual door.
1. Call of visitor
● CASE 1 : 1 Outdoor unit
- Call a DP
- 3HP from common entrance
a) Ring a chime sound.
b) Pick up a handset to talk.
c) While on the phone, press do or release button to open the door.
d) Leave the handset to end the talk.
● CASE 2 : 2 Outdoor unit
- Call a DP
- 3HP from common entrance (Outdoor unit 1)
a) Ring a chime sound.
b) Pick up a handset to talk.
c) While on the phone, press door release button to open the door.
d) Leave the handset to end the talk.
- Call a DP
- 3HP from common entrance (Outdoor unit 2)
a) Ring a chime sound.
b) Pick up a handset to talk.
c) While on the phone, press door release button to open the door.
d) Leave the handset to end the talk.

Commax DP-3HP Specifications

General

Power Voltage	AC220~, 50/60㎐
Power Consumption	MAX : 4 W (220V/60㎐)
Transmission	To Outdoor unit : 3 wires (Polarity)
Communication Method	Handset
Sound	From Outdoor unit : Electronic Chime
Time	60 ± 20 sec
Distance	28m(Ø0.5) / 50m(Ø0.65) / 70m(Ø0.8)
Operating Temperature	0 ~ +40℃(32℉~ 104℉)

Weight and Dimensions

Weight	0.55 ㎏
Dimension	107(W) x 195(H) x 52(D)㎜
