id8 data sheet – V1.0/1023 commend.com P 9 / 12Subject to change without notice.
ID8 TD/ID8 TD CM WITH DESK KIT ID8 DK AND GOOSENECK MICROPHONE ID8 GM
Measuring units in mm (in), not to scale!
276 (6.93)
102 (4.01)
149 (5.87)
max. 370 (14.6)
ID8 TD/ID8 TD CM WITH GYPSUM WALL/PANEL MOUNT KIT ID8 FB
Measuring units in mm (in), not to scale!
124 (4.88)
1)
42
(1.65)
16.5 (0.65)
2)
133 (5.24)
235 (9.25)
1)
3 (0.12) to
25 (0.98)
3)
3)
Wall/panel thickness
2)
Dimensions of the device
1)
Cut-out for wall mounting
